BioEntry P2

Compact IP Fingerprint Device

BioEntry P2
Compact IP Fingerprint Device
Features Configuration Specification Accessory Peripherals Download Video
WHERE TO BUY share
Suprema BioEntry P2 is a compact fingerprint access control device featuring Suprema’s next generation biometric technology and security platform. BioEntry P2 provides class-leading performance and security by featuring Suprema’s latest fingerprint algorithm coupled with powerful 1.0GHz CPU. Packed in a mullion-type sleek design, BioEntry P2 also provides added flexibility in system design by featuring multi card reading with dual-frequency RFID card technology.

Features

Best-in-Class Performance
BioEntry P2 features a class-leading 1.0GHz CPU that enhances user experience by offering World's best matching speed, high-precision OP6 optical sensor and the latest Suprema fingerprint algorithm.
Communicates with Smartphones
Supports NFC – allows you to use your Android smartphone as a key to access. (Not available for BLE support)
nfc
NFC (Near Field Communication)
Communicates via NFC’s HCE in Android
Protecting data communications using the AES encryption algorithm
Mullion-type Design
With its 50mm width, BioEtnry P2 perfectly fits in in narrow spaces and door frames
Interoperability by OSDP
By supporting latest OSDP V2 standards, BioEntry P2 is fully compatible with 3rd party OSDP compliance access controllers.
Dual Frequency, Multi-Smartcard Reader
Featuring dual-frequency RFID card technology, BioEntry P2 supports both LF(125kHz) and HF(13.56MHz) RFID including all RFID card standards that HID multiCLASS readers support. On top of fingerprint credential, BioEntry P2 supports most types of RFID card standards with a single device including MIFARE, HID iCLASS, DESFire, FeliCa, HID Prox, EM and NFC.
Versatile Interfaces
BioEntry P2 comes with not only a TCP/IP interface, but also more traditional interfaces (RS-485,Wiegand) to provide higher flexibility and multiple installation options for different environments. It also offers 2 internal inputs and 1 internal relay output to control peripheral devices. The I/O ports can also be expanded using the Secure I/O accessory.

Configuration

bioentry p2 configuration

Specification

Scroll left/right

Scroll left/right

Model Name

Credential

  • RF Option

  • RF read range 2)

Protections

  • IP rating

  • IK rating

Fingerprint

  • Template

  • Extractor / Matcher

  • Live Fingerprint Detection

Capacity

  • Max. User

  • Max. Credential (1:N)

  • Max. Credential (1:1)

  • Max. Text Log

  • Max. Image Log

General

  • CPU

  • Memory

  • Crypto Chip

  • LCD Type

  • LED

  • Sound

  • Operating Temperature

  • Storage Temperature

  • Operating Humidity

  • Storage Humidity

  • Weight

  • Dimension (WxHxD, mm)

  • Certifications

Interface

  • Wi-Fi

  • Ethernet

  • RS-485

  • RS-485 Communication Protocol

  • Wiegand

  • TTL Input

  • Relay

  • USB

  • SD Card

  • PoE

  • Intercom

  • Tamper

Electrical

  • Power

BEP2-OD

125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV31), FeliCa​

MIFARE/DESFire : 50 mm, EM/FeliCa : 30 mm​

Not supported

Not supported

SUPREMA / ISO 19794-2 / ANSI 378

MINEX certified and compliant

Not supported

10,000

Fingerprint: 10,000

Fingerprint: 10,000 Card: 10,000

1,000,000

Not supported

1.0 GHz

8GB Flash + 64MB RAM

Supported

Not supported

Multi-color

Multi-tone Buzzer

-20°C ~ 50°C (-4°F ~ 122°F)

-40°C ~ 70°C (-40°F ~ 158°F)

0% ~ 80%, non-condensing

0% ~ 90%, non-condensing

Device: 162g, Bracket: 39g (Including washer and bolt)

50.1 x 164 x 38 (mm)

CE, UKCA, KC, FCC, RCM, BIS, ANATEL, RoHS, REACH, WEEE

Not supported

Supported (10/100 Mbps, auto MDI/MDI-X)

1ch Master / Slave (Selectable)

OSDP V2 Compliant

1ch Input / Output (Selectable)

2ch Inputs

1 Relay

Not supported

Not supported

Not supported

Not supported

Supported

Voltage: 12 Vdc
Current: Max. 0.2 A

BEP2-OA

125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV31), FeliCa, iCLASS SE/SR/Seos​

MIFARE/DESFire/iCLASS : 50 mm, EM/HID Prox/FeliCa: 30 mm​

Not supported

Not supported

SUPREMA / ISO 19794-2 / ANSI 378

MINEX certified and compliant

Not supported

10,000

Fingerprint: 10,000

Fingerprint: 10,000 Card: 10,000

1,000,000

Not supported

1.0 GHz

8GB Flash + 64MB RAM

Supported

Not supported

Multi-color

Multi-tone Buzzer

-20°C ~ 50°C (-4°F ~ 122°F)

-40°C ~ 70°C (-40°F ~ 158°F)

0% ~ 80%, non-condensing

0% ~ 90%, non-condensing

Device: 162g, Bracket: 39g (Including washer and bolt)

50.1 x 164 x 38 (mm)

CE, UKCA, KC, FCC, RCM, BIS, ANATEL, RoHS, REACH, WEEE

Not supported

Supported (10/100 Mbps, auto MDI/MDI-X)

1ch Master / Slave (Selectable)

OSDP V2 Compliant

1ch Input / Output (Selectable)

2ch Inputs

1 Relay

Not supported

Not supported

Not supported

Not supported

Supported

Voltage: 12 Vdc
Current: Max. 0.2 A

1)DESFire EV2/EV3 cards are supported by having backward compatibility of DESFire EV1 cards. CSN and smart card functions are compatible with BioEntry P2.

2)RF read range will vary depending on installation environment.

Accessory

  • Power Adapter

Peripheral Device

Download

  • Firmware
    BioEntry P2 Firmware V1.5.1 EN
    Nov 27, 2023
    24.91 MB
    Download Share
  • Manual
    BioEntry P2 Installation Guide V1.06 EN
    Aug 03, 2023
    2.52 MB
    Preview Share
  • Product Images
    BioEntry P2 Image (Low Res)
    Nov 30, 2018
    39.99 MB
    Download Share
  • Product Images
    BioEntry P2 Image (High Res)
    Nov 30, 2018
    142.17 MB
    Download Share
  • Manual
    BioEntry P2 Drilling Template EN
    Nov 19, 2018
    430.06 KB
    Preview Share
  • Brochures
    BioEntry P2 Brochure EN
    Nov 19, 2018
    387.66 KB
    Preview Share
