XPass Q2

Intelligent QR RFID Reader

play_arrow Watch Video
Credentials Design Key Feature Configuration Specification
XPass Q2 Front
XPass Q2 Front
XPass Q2 Front
XPass Q2 Front
XPass Q2 Front
XPass Q2 Front
HIGHLIGHTS

XPass Q2

Intelligent QR/RFID reader.

XPQ2-DB

QR codes, barcodes
RFID: MIFARE / DESFire, EM, FeliCa
Mobile: NFC, BLE
IP65 - Outdoor-ready
Built-in door relay

Check all specs

CREDENTIALS

Can it SCAN? Then it CAN.

XPass Q2 reads just about anything: QR and barcodes on cards, phone, wristbands...
and the occasional wild idea.

QR Code

2D codes on phones or printed passes, widely used for tickets, visitor passes, and other app-less, temporary access credentials.

Supports QR codes of up to 32 ASCII characters, as well as Micro QR and Aztec formats.

Multi-credential support.

BioStar X Face - Multi-credential. One user, multiple ways in.

QR/Barcodes. Paper or mobile tickets for time-limited access to events and venues.

BioStar X Mobile credentials - Multi-credential. One user, multiple ways in.

Mobile (NFC/BLE). Smartphone-based credentials using NFC or BLE, enabling touchless, convenient, and highly secure access without physical cards.

BioStar X RFID - Multi-credential. One user, multiple ways in. BioStar X RFID - Multi-credential. One user, multiple ways in.
MIFARE DESFire EV1/EV2/EV3 EM FeliCa

RFID. Industry-standard RFID formats used for employee badges, membership cards, and multi-application access systems with strong compatibility across existing deployments. Supports a 200,000-user capacity for both 1:1 and 1:N operations.

BioStar X Remote Control - Multi-credential. One user, multiple ways in.

Remote door unlock. Trigger the device’s built-in relay from the BioStar X/2 platform to unlock doors instantly, no matter where you are.

Visitor management

Visitor management. Seamlessly check in guests using time-limited QR passes that enable fast, secure entry without issuing physical cards.

Membership management

Membership management. Support gyms, clubs, and facilities with QR or mobile-based member IDs, enabling quick authentication and smooth access for frequent users.

Shared office / gym

Shared office / gym. Provide flexible access for coworking spaces and fitness centers, where users authenticate with mobile QR codes, printed passes, or wristbands.

Ticket office

Ticket office. Enable rapid admission with QR or barcode tickets on phones or paper, ideal for events, concerts, and venues requiring fast, reliable throughput.

DESIGN

Sharp design that endures.

XPass Q2 combines an elegant, low-profile form with rugged construction. Its dark acrylic front and subtle lighting blend into modern architecture, while the IP65 enclosure is engineered for outdoor stadium entrances, gyms, coworking hubs, and other high-traffic sites that demand both style and durability.

XPASS Q2 LED backlit scan area
Clean LED backlit scan area
Integrated QR imaging module
XPASS Q2 LED backlit scan area

Clean LED backlit scan area & Integrated QR imaging module

XPASS Q2 LED backlit scan area
Slim mullion profile
XPASS Q2 LED backlit scan area

Slim mullion profile

XPASS Q2 LED backlit scan area
High-quality glass-like front
Minimal black and grey aesthetic
XPASS Q2 LED backlit scan area

High-quality glass-like front & Minimal black and grey aesthetic

XPASS Q2 LED backlit scan area
IP65 all-weather, rugged design
XPASS Q2 LED backlit scan area

IP65 all-weather, rugged design

Key Feature

Brains, brawn, and
speed to match.




High-Performance Processing

High-Performance
Processing.

1.0 GHz processor for fast QR decoding
and responsive access operations.

Fast, expanded memory

Fast, expanded memory.

256 MB RAM and 8 GB Flash ensuring smooth performance, quick data handling, and support for future firmware capabilities.

Secure boot

Integrated door
relay.

Provides local door control and drives locks or gates directly from the smart reader, enabling edge deployments without separate controllers.

Integrated door relay

Multi-color LED &
Multi-tone buzzer.

Clear visual and audio feedback for granted or denied access, improving usability even in noisy environments.

Multi-color LED & Multi-tone buzzer

Secure boot.

Cryptographically verified boot process that protects the device from tampering and unauthorized firmware.

Secure tamper

Secure tamper.

Real-time detection of physical interference or removal, enabling immediate alerts and data wipes.

Keep the line grooving.

XPass Q2 sweeps through eager crowds without skipping a beat. Its ultra-fast scanning keeps pace with busy, high-pressure environments, delivering quick, accurate reads even under heavy use.

5-15 cm

Scan distance

sweet-spot scanning distance with strong low-light decoding performance.

~30 People

Speed of throughput

per minute throughput with fast QR/barcode decoding for high-traffic entrances.

1 cm

Min. QR size

QR size supported with stable, high-accuracy decoding in real-world conditions.

  • User capacity 1:1 / 1:N
    Card: 200,000
    CPU
    1.0GHz
  • Log capacity
    1,000,000
    Ingress protection
    IP65
  • QR / Barcode
    DataMatrix, QR Code, Aztec, Micro QR Code, PDF417, Code39*, Code128*, UPC-A*, UPC-E*, EAN-8*, EAN-13*
  • RFID
    MIFARE, MIFARE Plus, DESFire EV1/EV2/EV3, 125kHz EM, FeliCa
    Size (WxHxD, mm)
    50 x 150 x 40.2
  • Mobile
    NFC, BLE
    Secure tamper
    Supported
  • Memory
    256MB RAM / 8GB Flash
    Certifications
    CE, UKCA, KC, FCC, IC, RCM, SIG, RoHS, REACH, WEEE, EAC, TELEC
Suprema XPass Q2

* To use more diverse QR/barcode authentication, a Camera QR license is required. For more
information about device licensing, please refer to the BioStar X administrative guide.

The device holds key certifications including ISO/IEC 27001, ISO/IEC 27701, which confirm its top-tier security in data protection.

ISO 27001
ISO 27701
NIS 2
GDPR
